Performance requirements of various parts of cold heading machine
(1) The connections between the crankshaft and the body and the impact connecting rod are all connected by high wear-resistant alloy copper tiles, which have large bearing capacity, long service life and low maintenance costs.
(2) The body is made of nodular iron with added alloy, which has high tensile strength and good wear resistance.
(3) The two-stage gear transmission system is adopted, which has high transmission efficiency and large transmission torque.
(4) Equipped with pneumatic clutch and brake to reduce motor power consumption.
(5) The cutting system adopts a guide plate to drive the cutter bar, the guide plate reciprocates, and the cutting force is transmitted in a straight line. The force is large and stable and the dynamic balance is good.
(6) The clamp system can be flipped or translated. Conducive to the arrangement of the molding process.
(7) Equipped with frequency conversion speed control device, which can adjust the speed steplessly within a certain range.
(8) Equipped with fault detector and safety protection device, it will automatically stop when the equipment fails, giving the equipment and tooling the maximum protection.
(9) The feeding box is equipped with a thrust device to improve feeding accuracy.
(10) The lubrication system oil circuit design is simple and efficient, which can effectively protect the punch and workpiece on the basis of ensuring circulating filtration.
